Manufactured in accordance with, tested & certified to individual Slant Sheets ie:(M17/028-RG058)
RoHS & REACH compliant insulating compounds
Test Reports with manufacturing lot for each & every cable
Certificate of Compliance with MIL-DTL-17
Made in the USA
High frequency RF antenna for ground support equipment
Radar systems & flight guidance equipment
Secure & cryptic aerospace communications

Interested in this item or want more information?
Call Mon. through Fri. 7:30 AM - 4:00 PM PST
Phone: (415) 822-4334
Email: Jon@LevelSupply.com

Can't find what you want? Give us a call and we can help you find it.

Details

Construction Parameters

Electrical Properties


		Wall (in)*	OD (in)*
Conductor	20 AWG (19/33) Tinned Coated Copper		0.035
Dielectric	Solid Polyethylene color natural	0.041	0.116
Shielding	93% Tinned Coated Copper Braid		0.138
Jacket	PVC (Non-Contaminating Vinyl)	0.029	0.195

		VALUE*
Conductor Resistance (Max./100 ft)		1.24
Impedance (ohms)		50
Capacitance (Max. pF/ft)		32.2
Velocity of Propagation (%)		66
Attenuation (Max db/100 ft)	50 MHz	4
	100 MHz	6.5
	400 MHz	17.0
	1000 MHz	28.0
SRL (Min: dB)	100 MHz	27.3
	500 MHz	25.0
	800 MHz	24.0
	1000 MHz	24.5

Additional Information

Manufacturer: Coleman Cable - CCI

For More Information on the M17/28-Rg058, [Click Here] to Link to Manufacturer Web Site
