Manufactured in accordance with, tested & certified to individual Slant Sheets ie:(M17/028-RG058)
RoHS & REACH compliant insulating compounds
Test Reports with manufacturing lot for each & every cable
Certificate of Compliance with MIL-DTL-17
Made in the USA
High frequency RF antenna for ground support equipment
Radar systems & flight guidance equipment
Secure & cryptic aerospace communications

Interested in this item or want more information?
Call Mon. through Fri. 7:30 AM - 4:00 PM PST
Phone: (415) 822-4334
Email: Jon@LevelSupply.com

Can't find what you want? Give us a call and we can help you find it.

Details

Construction Parameters

Electrical Properties


		Wall (in)*	OD (in)*
Conductor	23 AWG Solid Copper Covered Steel		0.035
Dielectric	Solid Polyethylene color natural	0.062	0.146
Shielding	95% Solid Bare Copper Braid		0.174
Jacket	Type II Non Contaminating PVC	0.029	0.195

		VALUE*
Impedance (ohms)		75
Capacitance (Max. pF/ft)		22.0
Velocity of Propagation (%)		66
Attenuation (Max db/100 ft)	50 MHz	1.9
	100 MHz	2.7
	200 MHz	41
	400 MHz	8.0
	1000MHz	13.0

Additional Information

Manufacturer: Coleman Cable - CCI

For More Information on the M17/29-Rg059, [Click Here] to Link to Manufacturer Web Site
